RT175MCH1 04 – SHELVES AND SUPPORTS

RT175MCH1 04 – SHELVES AND SUPPORTS

Written by

in

RT175MCH1 04 – SHELVES AND SUPPORTS

Products

PositionProduct
1WCI 3206187
2EWCI G186773
2ASUPPORT-SHELF (2)
2BSCREW (2)
2SHELF-ICEMAKER
2CHANGER-SHELF (NON-ILLUSTRATED)
3WCI 3206120
4SHELF-SLIDING, REFR, (3)
5FRONT-CRISPER PAN-LH
6WCI 3206183
7PAN – CRISPER
8WCI 5303206753
9WASHER, NO. 10 STEEL, 7/32 X 7/16 OD (NOT ILLUSTRATED)
10A5304455650 Frigidaire Refrigerator Screw
10WCI 3206130
11WCI 5303201777
12WCI 3206129
135304455852 Frigidaire Refrigerator Screw
14WCI 5303018894
14AWCI 5303001260
15WCI 3018891
16215846602 Frigidaire Refrigerator 8-Hour Defrost Timer
16A5304455649 Frigidaire Refrigerator Screw
17218906802 Frigidaire Light Lamp Socket
18316538904 Frigidaire Oven Lamp Light
195309918806 Frigidaire Refrigerator Light Switch Door
20WCI 3206185
20AWCI 5303001380
21WCI 3206182
22WCI 5303207247
23B3205266 Frigidaire Refrigerator Edge Protector
23WCI 3206186
23AWCI 3018900
24WCI 3206123
