RT176LCD0 03 – CABINET PARTS

Products

Position	Product
1	WCI G162178
2	DEFLECTOR AIR
3B	WCI G142361
3	BRACKET-LOWER HINGE
3D	WCI G141673
3C	NUT, SPEED (2)
3A	SCREW – 1/4 X 1 (2)
4	ROLLER ASSY (2)
5	BRACKET, TOP HINGE
6	WCI G183861
7	WASHER, NYLON
8	241710601 Frigidaire Refrigerator Screw
9	WCI G166171
10	WCI G155529-04
11	COVER, TOP HINGE, AVOCADO
11	COVER HINGE, COFFEE
11	COVER HINGE, WHITE
11	COVER HINGE, WHEAT
11	COVER, TOP HINGE, ALMOND
12	ROLLER (2)
14	WCI G162809
15	WCI G142220
16	SCREW, BRACKET MOUNTING (4)
17	WCI G162384
18	SHIM, HINGE
19	CHANNEL, CENTER SHELF, MOUNTING
20	TAPPING, PLATE (2)
21	CHANNEL, SHELF (2)
22	STRAP, MULLION MOUNTING
23	WCI G174733
24	TUBE, INSULATION (2)
25	PLUG, DECORATIVE
26	DAMPER FAN COVER
27	NUT, DAMPER MOUNTING
28	WCI G162663-15
29	COVER
30	5304455650 Frigidaire Refrigerator Screw
31	WCI G162994
32	WCI G163080-03
33	BUTTON, LINER
34	5308000010 Frigidaire Refrigerator Evaporator Fan Blade
35	RING, FAN ORIFICE
36	G187559 Frigidaire Refrigerator Bushing
37	5300158289 Frigidaire Evaporator Fan Motor
38	WCI G185302
39	WCI G185303
40	WCI G162050-01
41	WCI G170071
42	SHIM, HINGE
43	WCI G174734
44	WCI G163669
