RT17F2WU3A 03 – CABINET PARTSadmin2025-04-26T10:32:03+00:00RT17F2WU3A 03 – CABINET PARTS
Products
| Position | Product |
|---|
| *56246 | CABINET BASE |
| *56249 | BUTTON-DECORATIVE |
| *56250 | BUTTON, PLUG, LINER (2) |
| *56247 | HARNESS, WIRING |
| 1 | WCI G163669 |
| 2 | BRACKET, TOP HINGE |
| 2C | WASHER, NYLON 5/16 X 5/8 (CTR & LOWER HINGE BRACKET) |
| 2B | WCI G174747-11 |
| 2A | WCI G103903 |
| 2B | WCI G174747-08 |
| 2B | WCI G174747--01 |
| 2B | WCI G174747-09 |
| 2B | WCI G174747-10 |
| 3 | WCI G183861 |
| 4B | WCI G142220 |
| 4A | SCREW, BRACKET MOUNTING (4) |
| 4 | BRACKET, HINGE CENTER |
| 5B | TAPPING PLATE (2) |
| 5A | 5303001321 Frigidaire Refrigerator Lower Hinge Pin |
| 5 | BRACKET-HINGE |
| 6 | SHIM, HINGE |
| 7 | WCI G174733 |
| 8 | WCI G174734 |
| 9 | BOTTOM, FC |
| 10A | SCREW (5) |
| 10 | TOP PC |
| 11 | DIVIDER, CENTER |
| 12 | SPOUT DRAIN TUBE |
| 13 | LABEL-CONTROL BOX (NON-ILLUSTRATED) |
| 14 | KNOB-DAMPER |
| 15 | DAMPER FAN COVER |
| 15A | NUT, DAMPER MOUNTING |
| 16 | SOCKET LIGHT |
| 17 | 316538904 Frigidaire Oven Lamp Light |
| 18 | CONTROL |
| 18A | WCI G107080 |
| 19 | WCI G174765-03 |
| 20 | TUBE |
| 21 | KNOB-TEMP CONTROL |
| 22 | 5309918806 Frigidaire Refrigerator Light Switch Door |
| 23 | COVER-COIL |
| 24 | WCI G185303 |
| 25 | WCI G185302 |
| 26 | 5300158289 Frigidaire Evaporator Fan Motor |
| 27 | RING, FAN ORIFICE |
| 27A | NUT, ORIFICE (2) |
| 28A | 5304455650 Frigidaire Refrigerator Screw |
| 28 | 5308000010 Frigidaire Refrigerator Evaporator Fan Blade |
| 29 | WCI G163061-81 |
| 30 | WCI G178402-05 |
| 31 | WCI G164571 |
| 31A | 5304455651 Frigidaire Refrigerator Screw |
| 32 | DEFLECTOR AIR |
| 33 | WCI G162178 |
| 34A | WASHER (2) |
| 34 | SPACER, MULLION (2) |
| 35 | PAD, FOAM (2) |
| 36 | CLAMP, MULLION MOUNTING |
| 37 | WCI G490086-09 |
| 37 | WCI G490086-10 |
| 37 | WCI G490086-01 |
| 37 | WCI G490086-11 |
| 37 | MULLION, AVOCADO |
| 38 | HTR, CENTER RAIL |
| 39 | TUBE, INSULATION (2) |
| 40 | 215846602 Frigidaire Refrigerator 8-Hour Defrost Timer |
| 40A | 5304455649 Frigidaire Refrigerator Screw |
| 41 | PAN-SMALL LS |
| 41 | PAN-CRISPER |
| 42 | TUBE, DRAIN |
| 43 | COVER, TOP HINGE, AVOCADO |
| 43 | COVER, TOP HINGE, ALMOND |
| 43 | COVER HINGE, WHITE |
| 43 | COVER HINGE, WHEAT |
| 43 | COVER HINGE, COFFEE |
| 44 | COVER-CRISPER |
| 45 | SUPPORT, CRISPER COVER |
| 46 | G187559 Frigidaire Refrigerator Bushing |
| 47 | TROUGH-DRAIN |
| 48 | WCI G179684-09 |
| 48 | WCI G179684-10 |
| 48 | WCI G179684-01 |
| 48 | TRIM-CORNER, ALMOND (4) |
| 48 | TRIM CORNER (4), AVOCADO |
| 49 | 215667501 Frigidaire Refrigerator Ice Tray Primary |
| 50 | WCI G166912 |
| 51 | LEG-LEVELING (2) |
| 51A | NUT, ANCHOR (2) |
| 52 | SHELF |
