RT18EKRXL01 08 – UNIT, LIT/OPTIONAL

RT18EKRXL01 08 – UNIT, LIT/OPTIONAL

Written by

in

RT18EKRXL01 08 – UNIT, LIT/OPTIONAL

Products

PositionProduct
350930 Whirlpool White Spray Paint
1129316 Whirlpool Refrigerator Ice Maker Kit Square Plug
Torx Key
WPL LIT2149680
WPL LIT2152381
WPL LIT4361084
Leveler (Thinner)
WPL LIT2152383
285006 Whirlpool Spray
350942 Whirlpool Spray Paint
2Bumper (2)
3Condenser & Precooler Assembly
4Clip, Tube (2)
5Support, Heater
6Spacer
7Heat Shield Evaporator
8Clamp Tube
9Dampener
10WP489174 Whirlpool Refrigerator Screw
12Cover
13Overload
14Tube, Clamp
16WPW10662129 Whirlpool Refrigerator Run Capacitor
19Screw, 8-32 x 1/2
20Condenser, Stand-Off
21WP489478 Whirlpool Refrigerator Screw
22Evaporator
234386951 Whirlpool Refrigerator Clip
24285002 Whirlpool Nut
25Evaporator Tray
26Restrictor Sleeve
27W10843121 Whirlpool Refrigerator Tube
28Compressor (Includes Items 43, 44, 45, 46, 47, 51, & 52) (Also Order 482801 Mounting Kit & 876765 Tu
29Clamp, Dryer
30Unit Mounting Plate
31Exchanger, Heat
32Clip, Stand Off
33Heater, Defrost
35WPW10225581 Whirlpool Refrigerator Defrost Thermostat
36Condenser, Stand-Off
39876811 Whirlpool Grommet
43WP2262181 Whirlpool Refrigerator Start Relay
44Overload
45Cover, Terminal
46Strap
47Capacitor
48Unit Mounting Rail
49WP965173 Whirlpool Dishwasher Screw
50WP489427 Whirlpool Refrigerator Screw
51WP2002171 Whirlpool Refrigerator Sleeve
55Nut
56Washer
57VALVE, ACCESS (5/8“)
57WP503695 Whirlpool Refrigerator Sealer
57876370 Whirlpool Refrigerator Insulation
57833938 Whirlpool Refrigerator Terminal
57212643 Whirlpool Refrigerator Permagum Sealer
57606755 Whirlpool Refrigerator Bag
57799344 Whirlpool Refrigerator Paint
57511873 Whirlpool Refrigerator Paint
57876764 Whirlpool Refrigerator Primary Valve
57978026 Whirlpool Refrigerator Primary Valve
57Overload Spring
57WPL 876029
5772032 Whirlpool Touch Up Paint Black
57WPL 799833
57CEMENT, ALUMILASTIC (1 1/4 OZ.)
57TAPE, VINYL (3/4 X 108“)
57VALVE, ACCESS (1/2“)
57WP978025 Whirlpool Refrigerator Valve
57978030 Whirlpool Refrigerator Valve
57WP542638 Whirlpool Refrigerator Grease
57978027 Whirlpool Refrigerator Primary Valve
57WP505587 Whirlpool Refrigerator Sealer
5772017 Whirlpool Appliance Touch-Up Paint White
