RT194LCDO 03 – SHELVES

Products

Position	Product
*91803	BUTTON, LINER
*91812	5304455651 Frigidaire Refrigerator Screw
*91806	WASHER (2)
*91808	WCI G107080
*91805	SCREW (5)
*91810	LABEL-BOX
*91802	5304500407 Frigidaire Refrigerator Shelf Mounting Grommet
*91809	5304455650 Frigidaire Refrigerator Screw
*91813	241710601 Frigidaire Refrigerator Screw
*91804	HARNESS, WIRING
*91807	5304455649 Frigidaire Refrigerator Screw
1	COVER, TOP HINGE, ALMOND
3	WCI G183861
4	WCI G103903
5	WASHER, NYLON 5/16 X 5/8 (CTR & LOWER HINGE BRACKET)
6	ROLLER, REAR (2)
7	BOLT ROLLER (2)
8	ROLLER FRONT, ADJUSTABLE (2)
9	SPRING-ROLLER (2)
10	SUPPORT, ROLLER (2)
11	BOLT-ROLLER (2)
12	WASHER
13	WCI G166912
14	SHIM, HINGE
15	5303001321 Frigidaire Refrigerator Lower Hinge Pin
16	BRACKET-HINGE
17	WCI G179415-02
18	WCI G176639-22
19	WCI G490015-01
20	WCI G490064-03
21	SUPPORT, CRISPER COVER
22	WCI G176918-22
23	WCI G177106-06
24	WCI G184193-02
25	WCI G166495-01
26	215667501 Frigidaire Refrigerator Ice Tray Primary
27	CONTROL BOX
28	KNOB
29	WCI G178402-02
30	WCI 3200810
31	TUBE
32	215846602 Frigidaire Refrigerator 8-Hour Defrost Timer
33	SOCKET LIGHT
34	WCI Q63749
35	DEFLECTOR AIR
36	WCI G162178
37	WCI G142220
38	BRACKET, HINGE CENTER
39	SCREW, BRACKET MOUNTING (4)
40D	WCI G180373-11
41	WCI G177254
42	SPACER, MULLION (2)
43	STRAP, MULLION MOUNTING
44	5309918806 Frigidaire Refrigerator Light Switch Door
45	TOP-REFRIGERATOR
46	DIVIDER, CENTER
47	BOTTOM, FC
48	5304509705 Frigidaire Refrigerator Grommet
49	WCI G163669
50D	TRIM-CORNER, ALMOND (4)
51D	WCI GA74747-11
52	WCI G174733
53	WCI G174734
54	TUBE, INSULATION (2)
55	WCI G490004-02
56	LEG-LEVELING (2)
57	NUT, ANCHOR (2)
