RT194LCV0 03 – CABINET PARTS

Products

Position	Product
1	COVER, TOP HINGE, AVOCADO
2A	241710601 Frigidaire Refrigerator Screw
2	BRACKET, TOP HINGE
3	WCI G183861
4	WCI G103903
5	WASHER, NYLON 5/16 X 5/8 (CTR & LOWER HINGE BRACKET)
6	ROLLER, REAR (2)
7	BOLT ROLLER (2)
7A	5304455651 Frigidaire Refrigerator Screw
8	ROLLER FRONT, ADJUSTABLE (2)
9	SPRING-ROLLER (2)
10	SUPPORT, ROLLER (2)
11	BOLT-ROLLER (2)
12	WASHER
13	WCI G166912
14	SHIM, HINGE
15	5303001321 Frigidaire Refrigerator Lower Hinge Pin
16	BRACKET-HINGE
17	WCI G179415-02
18	WCI G176639-22
19	WCI G490015-01
20	WCI G490064-03
21	SUPPORT, CRISPER COVER
22	WCI G176918-22
23	WCI G177106-06
24	WCI G184193-02
25	WCI G166495-01
26	215667501 Frigidaire Refrigerator Ice Tray Primary
27B	5304455650 Frigidaire Refrigerator Screw
27A	LABEL-BOX
27	CONTROL BOX
28	KNOB
29	WCI G178402-02
30	WCI 3200810
30A	WCI G107080
31	TUBE
32	215846602 Frigidaire Refrigerator 8-Hour Defrost Timer
32A	5304455649 Frigidaire Refrigerator Screw
33	SOCKET LIGHT
34	WCI Q63749
35	DEFLECTOR AIR
36	WCI G162178
37	WCI G142220
38	BRACKET, HINGE CENTER
39	SCREW, BRACKET MOUNTING (4)
39A	WASHER (2)
40	WCI G180373-08
41	WCI G177254
42	SPACER, MULLION (2)
43	STRAP, MULLION MOUNTING
44	5309918806 Frigidaire Refrigerator Light Switch Door
45	TOP-REFRIGERATOR
45A	SCREW (5)
46A	HARNESS, WIRING
46	DIVIDER, CENTER
47	BOTTOM, FC
48	5304509705 Frigidaire Refrigerator Grommet
48A	5304500407 Frigidaire Refrigerator Shelf Mounting Grommet
48B	BUTTON, LINER
49	WCI G163669
50	TRIM CORNER (4), AVOCADO
51	WCI G174747-08
52	WCI G174733
53	WCI G174734
54	TUBE, INSULATION (2)
55	WCI G490004-02
56	LEG-LEVELING (2)
57	NUT, ANCHOR (2)
