RT194LCV1 03 – CABINET PARTS

Products

Position	Product
*35191	PLUG, BUTTON, CABINET LINER (NI)
1A	WCI G000187640
1	WCI 5349007601
2	WCI 5316266315
3	Nut,push-on
4	DAMPER-FAN COVER
5	5308000010 Frigidaire Refrigerator Evaporator Fan Blade
6	218843801 Frigidaire Refrigerator Screw
7	RING-FAN ORIFICE
8	G187559 Frigidaire Refrigerator Bushing
9	WCI 5303001226
10B	5304455650 Frigidaire Refrigerator Screw
10	WCI 5308009771
10A	NUT, “U“ TYPE, NO. 8-15(A), FAN MOTOR MOUNT (NOT ILLUSTRATED)
11	5303208309 Frigidaire Refrigerator Plug Hole
12	PLUG-DECORATIVE, ICE MAKER HOLE
13	5300158289 Frigidaire Evaporator Fan Motor
14	WCI 5303001227
15	WCI 5308000107
17	WCI 5303001470
18	SUPPORT-COIL COVER
19	TUBE-RUBBER
20	WCI 5303001286
21	WCI 5303001287
22	BUTTON-HINGE-AVOCADO
23	WCI 5303210377
24	BRACKET-UPPER HINGE
25	SHIM – UPPER HINGE
26	CABINET BASE
27	SCREW-LEVELING (4)
28	WCI 5308003584
29	COVER-HOLE, LOWER HINGE
30	HINGE BRACKET – BOTTOM
30A	241710601 Frigidaire Refrigerator Screw
31	SHIM-LOWER HINGE
31A	TAPPING PLATE, UPPER HINGE (2) (NOT ILLUSTRATED)
32	5303001321 Frigidaire Refrigerator Lower Hinge Pin
33	WCI 5308000186
35A	WCI 5308012258
35	BRACKET-CTR HINGE
36	WCI 5308000184
37	CORNER
38	COVER-HINGE-AVOCADO
39	WCI 5308009773
40A	5304455651 Frigidaire Refrigerator Screw
40	BOLT-ROLLER MTG, HEX WASHER HEAD, 1/4-28 X 1/2, (2)
41	WCI 5308009760
42	WCI 5308009790
43	SUPPORT, BASE (2)
44	BOLT-ROLLER ADJ, (2) (NON-ILLUSTRATED)
45	WCI 5308011326
46	WCI 5303207353
47	WCI 5308000056
48	WCI 5303001361
