RT194LCW1 03 – CABINET PARTS

Products

PositionProduct
*35191PLUG, BUTTON, CABINET LINER (NI)
1AWCI G000187640
1WCI 5349007601
2WCI 5316266315
3Nut,push-on
4DAMPER-FAN COVER
55308000010 Frigidaire Refrigerator Evaporator Fan Blade
6218843801 Frigidaire Refrigerator Screw
7RING-FAN ORIFICE
8G187559 Frigidaire Refrigerator Bushing
9WCI 5303001226
10WCI 5308009771
10ANUT, “U“ TYPE, NO. 8-15(A), FAN MOTOR MOUNT (NOT ILLUSTRATED)
10B5304455650 Frigidaire Refrigerator Screw
115303208309 Frigidaire Refrigerator Plug Hole
12PLUG-DECORATIVE, ICE MAKER HOLE
135300158289 Frigidaire Evaporator Fan Motor
14WCI 5303001227
15WCI 5308000107
17WCI 5303001470
18SUPPORT-COIL COVER
19TUBE-RUBBER
20WCI 5303001286
21WCI 5303001287
22PLUG-BUTTON, WHITE
23WCI 5303210377
24BRACKET-UPPER HINGE
25SHIM – UPPER HINGE
26CABINET BASE
27SCREW-LEVELING (4)
28WCI 5308003584
29COVER-HOLE, LOWER HINGE
30A241710601 Frigidaire Refrigerator Screw
30HINGE BRACKET – BOTTOM
31ATAPPING PLATE, UPPER HINGE (2) (NOT ILLUSTRATED)
31SHIM-LOWER HINGE
325303001321 Frigidaire Refrigerator Lower Hinge Pin
33WCI 5308000186
35BRACKET-CTR HINGE
35AWCI 5308012258
36WCI 5308000184
37TRIM-CABINET CORNER, WHITE
38COVER-UPPER HINGE, WHITE
39WCI 5308009773
40BOLT-ROLLER MTG, HEX WASHER HEAD, 1/4-28 X 1/2, (2)
40A5304455651 Frigidaire Refrigerator Screw
41WCI 5308009760
42WCI 5308009790
43SUPPORT, BASE (2)
44BOLT-ROLLER ADJ, (2) (NON-ILLUSTRATED)
45WCI 5308011326
46WCI 5303207353
47WCI 5308000056
48WCI 5303001361
