RT196LCW0 03 – CABINET PARTS

Products

Position	Product
*11057	TAPPING, PLATE (2)
*11057	BUTTON, LINER
1	COVER HINGE, WHITE
2	BRACKET, TOP HINGE
3	WCI G183861
4	241710601 Frigidaire Refrigerator Screw
5	WCI G103903
6	WASHER, NYLON 5/16 X 5/8 (CTR & LOWER HINGE BRACKET)
7	ROLLER ASSEMBLY – FRONT (2)
8	SCREW, MTG (2) (NON-ILLUSTRATED)
9	WCI G163080-03
10	WCI G162994
11	ROLLER (2)
12	WCI G162809
14	WCI G183584
15	BRACKET-LOWER HINGE
16	SHIM, HINGE
17	ELBOW, DRAIN
19	SUPPORT, SHELF (8)
20	DEFLECTOR AIR
21	WCI G162178
22	SCREW-SUPPORT MOUNTING (4) (NON-ILLUSTRATED)
23	WCI G174733
24	WCI G177734
25	PLUG, DECORATIVE
26	DAMPER FAN COVER
27	NUT, DAMPER MOUNTING
28	WCI G162663-15
29	WCI G179793-02
29A	5304455650 Frigidaire Refrigerator Screw
30	LABEL-FAN CVR
31	SPOUT DRAIN TUBE
32	PIN PUSH SPOUT (2)
33	TUBE-DRAIN
34	5308000010 Frigidaire Refrigerator Evaporator Fan Blade
35	RING, FAN ORIFICE
36	G187559 Frigidaire Refrigerator Bushing
37	5300158289 Frigidaire Evaporator Fan Motor
38	WCI G185302
39	WCI G185303
40	TUBE, INSULATION (2)
41	WCI G162050-02
41A	NUT, ORIFICE (2)
42A	SHIM, HINGE
42	WCI G162384
43	SCREW, BRACKET MOUNTING (4)
44	WCI G142220
45	WCI G170071
46	CHANNEL, SHELF (2)
47	5304455852 Frigidaire Refrigerator Screw
48	CHANNEL, CENTER SHELF, MOUNTING
49	SCREW (3) (NON-ILLUSTRATED)
50	WCI G163669
51	WCI G174747–01
