RT20CKXWL00 07 – REFRIGERATOR DOOR, LIT/OPTIONAL

RT20CKXWL00 07 – REFRIGERATOR DOOR, LIT/OPTIONAL

Written by

in

RT20CKXWL00 07 – REFRIGERATOR DOOR, LIT/OPTIONAL

Products

Position	Product
	Torx Key
	1129316 Whirlpool Refrigerator Ice Maker Kit Square Plug
	WPL LIT1127854
	WPL LIT4316101
	WPL LIT2150138
	WPL LIT2148390
1	Panel, Refrigerator Door (White)
1	Panel, Refrigerator Door (Almond)
2	Hole Plug (2)
3	W10833053 Whirlpool Refrigerator Plate
4	Bracket, Door Stop
5	WP488921 Whirlpool Refrigerator Screw
6	WP8281206 Whirlpool Refrigerator Screw
7	WP2212648 Whirlpool Refrigerator Hinge Sleeve Hole Plug
7	Hole Plug (Almond)
8	2188450A Whirlpool Refrigerator Door Gasket
9	WP489069 Whirlpool Compactor Screw
10	Handle End
11	Handle End,
12	Handle, Center
13	Shim, Handle
14	Spa
15	WP939101 Whirlpool Refrigerator Plate
16	WP488920 Whirlpool Refrigerator Screw
17	WP488729 Whirlpool Refrigerator Door Screw
18	Cover, End Cap
19	Interior Door Panel
20	Trim, Door (2)
21	Trim, Door
22	Compartment Door, Utility
23	Compartment, Butter Door
24	WP2189000 Whirlpool Refrigerator Handle Plug
24	Hole Plug, Handle (Almond)
28	Cap, Hinge Sleeve (2)
29	4318297 Whirlpool Refrigerator Shelf Bar Endcap Kit, 2 Pack
30	WP72107 Whirlpool Touchup
30	799344 Whirlpool Refrigerator Paint
30	350930 Whirlpool White Spray Paint
30	Leveler (Thinner)
30	Almond (Uncut)
30	350956 Whirlpool Spray Assembly
30	72017 Whirlpool Appliance Touch-Up Paint White
30	212643 Whirlpool Refrigerator Permagum Sealer
30	TAPE, VINYL (3/4 X 108“)
30	CEMENT, ALUMILASTIC (1 1/4 OZ.)
30	WP505587 Whirlpool Refrigerator Sealer
30	WPL 876029
30	WP503695 Whirlpool Refrigerator Sealer
30	876370 Whirlpool Refrigerator Insulation
30	833938 Whirlpool Refrigerator Terminal
30	285006 Whirlpool Spray
30	72032 Whirlpool Touch Up Paint Black
30	606755 Whirlpool Refrigerator Bag
30	511873 Whirlpool Refrigerator Paint
30	WPL 799833
30	4386917 Whirlpool Endcap Kit
30	350942 Whirlpool Spray Paint
30	WP542638 Whirlpool Refrigerator Grease
