RT215LCD0 04 – SHELVES AND SUPPORTSadmin2025-04-26T10:25:18+00:00RT215LCD0 04 – SHELVES AND SUPPORTS
Products
| Position | Product |
|---|
| 1 | PAN-CRISPER R.S. |
| 2 | WCI 3001642 |
| 3 | COVER-PAN |
| 4 | ROD, CRISPER COVER SUPT |
| 5 | GASKET, COVER |
| 6A | WCI G177343-06 |
| 6 | PAN, MEAT |
| 7B | SCREW-HANGER (2) (NON-ILLUSTRATED) |
| 7 | WCI G187251-01 |
| 7A | HANGER, MEAT PAN RH |
| 8 | FRAME, SHELF |
| 9 | TRIM, REAR |
| 10 | GLASS-SHELF |
| 11 | TRIM-SHELF |
| 12 | FRAME-SHELF |
| 13 | TRIM, REAR |
| 14 | FRAME-SHELF FULL (NON-ILLUSTRATED) |
| 15 | GLASS-SHELF (NON-ILLUSTRATED) |
| 16 | TRIM-FRONT (NON-ILLUSTRATED) |
| 17 | TRIM-REAR (NON-ILLUSTRATED) |
| 18 | WCI G176722-01 |
| 18A | 5304455650 Frigidaire Refrigerator Screw |
| 19 | WCI 3200810 |
| 19A | WCI G107080 |
| 20 | TUBE |
| 21A | 5304455649 Frigidaire Refrigerator Screw |
| 21 | 215846602 Frigidaire Refrigerator 8-Hour Defrost Timer |
| 22 | 316538904 Frigidaire Oven Lamp Light |
| 23 | SOCKET LIGHT |
| 24 | KNOB |
| 25 | WCI G178402-02 |
| 26 | WCI G180197 |
| 27 | WCI G180373-11 |
| 28 | SCREW, BRACKET MOUNTING (4) |
| 29 | STRAP, MULLION MOUNTING |
| 30 | WASHER (2) |
| 31 | SPACER, MULLION (2) |
| 32 | WCI 3018916 |
| 33 | 5309918806 Frigidaire Refrigerator Light Switch Door |
| 34 | TOP-REFRIGERATOR |
| 34A | SCREW (5) |
| 35 | WCI G184683 |
| 36 | WCI G184604 |
| 37 | WCI G177059-05 |
| 38 | END CAP-SHELF,PROTECTOR |
| 39 | TRIM-FRONT |
| 40 | CONTAINER-EGG |
