RT215MCF0 02 – DOOR PARTS

Products

Position	Product
*24088	WCI G000179271
*24088	WCI 5303206514
*24088	WCI 3206307
*24088	INSULATION-BULK
1	WCI G187355-10
2	WCI G169332-10
3	BEARING, HINGE (3)
4	WCI 3206159
5	DOOR STOP (2)
8	WCI G162977-10
9	WCI G185566
10	WCI G186803-14
11	WCI 5303206509
12	RACK-DOOR, FULL-WIDTH, WIDE
13A	SUPPORT-DOOR RACK, EXTENDS 1.06“, LH
13	SUPPORT-DOOR RACK, EXTENDS 1.06“, RH
15	RACK-DOOR, SHORT, NARROW, (2)
16	WCI 5303206519
16A	TRIM-DAIRY DOOR (NON-ILLUSTRATED)
17	HANDLE-FREEZER
18	5304455651 Frigidaire Refrigerator Screw
19	WCI 3018792
20	WCI 5303206518
21	WCI 5303206513
22	WCI G187356-10
23	HANDLE-REF
24	WCI 5303206511
25	WCI 3206189
26A	SUPPORT-DOOR RACK, LH
26	SUPPORT-DOOR RACK, RH
27	WCI 5303206515
28A	3206166 Frigidaire Refrigerator Freezer Door Shelf Retainer Bar Endcap Rack Support
28	3206165 Frigidaire Bar Endcap Right Hand
29A	WCI G000177144
29B	WCI G000179270
29	CAP
30	WCI G000177143
