RT216JCD2 04 – SHELVES AND SUPPORTS

RT216JCD2 04 – SHELVES AND SUPPORTS

Written by

in

RT216JCD2 04 – SHELVES AND SUPPORTS

Products

PositionProduct
1WCI 3001642
2TRIM-PAN RH
3PAN-CRISPER R.S.
4ROD, CRISPER COVER SUPT
5WCI 3007603
6GASKET, COVER
7TRIM-FRONT (NON-ILLUSTRATED)
8WCI 3001639
9TRIM-FRONT (3)
10WCI R000901104
11PAN, MEAT
12WCI G177106-06
13TRIM-FRONT
14WCI G177059-05
14AEND CAP-SHELF,PROTECTOR
15ASCREW (5)
15TOP-REFRIGERATOR
165309918806 Frigidaire Refrigerator Light Switch Door
17WCI 3018916
18WCI 3200370
19SCREW, BRACKET MOUNTING (4)
20STRAP, MULLION MOUNTING
21WASHER (2)
22SPACER (NON-ILLUSTRATED)
23WCI G184683
24WCI G184604
25316538904 Frigidaire Oven Lamp Light
26SOCKET LIGHT
27WCI G176722-01
28WCI G180197
29KNOB
30WCI G178402-02
31TUBE
32AWCI G107080
32WCI 3200810
33A5304455649 Frigidaire Refrigerator Screw
33215846602 Frigidaire Refrigerator 8-Hour Defrost Timer
34215667501 Frigidaire Refrigerator Ice Tray Primary
35WCI G186095-02
35A5304455650 Frigidaire Refrigerator Screw
36TRIM-PAN LH
37WCI G177343-02
