RT216JCD5 02 – DOOR PARTS

Products

PositionProduct
*41720INSULATION-BULK (NON-ILLUSTRATED)
1GASKET-FRZR
2INTERIOR PANEL-FREEZER
3WCI 5308000255
3ADOOR STOP, REFR SECTION
4PLUG-BUTTON, ALMOND, HANDLE/DR STOP
5WCI 5300304001
6PLUG-BUTTON, ALMOND, HINGE BRG HOLE
7WCI 17714107
8WCI 5308011745
9WCI 5300179270
10WCI 5300179271
11WCI 5300177142
12AWCI 5300177144
12WCI 5300177143
13WCI G187355-11
14BEARING-HINGE
15PANEL-REFRIGERATOR-ALMOND
16WCI 5317394819
175308000716 Frigidaire Refrigerator Dish
18GASKET-REFRIG DOOR
19PANEL-INNER REFRIGERATOR
20WCI 5316101951
21RACK-REFRIG (2)
22WCI 5303007295
23WCI 5303007297
24DOOR-DAIRY (2)
255304455651 Frigidaire Refrigerator Screw
