RTG216JCD3A 03 – CABINET PARTS

Products

Position	Product
*26337	5304500407 Frigidaire Refrigerator Shelf Mounting Grommet
*26337	5304509705 Frigidaire Refrigerator Grommet
*26337	BUTTON, LINER
1	WCI G185303
2	5300158289 Frigidaire Evaporator Fan Motor
3	WCI G164571
4	WCI G185302
5	RING, FAN ORIFICE
5A	5304455651 Frigidaire Refrigerator Screw
6	G187559 Frigidaire Refrigerator Bushing
7	5308000010 Frigidaire Refrigerator Evaporator Fan Blade
8	DAMPER FAN COVER
9	NUT, DAMPER MOUNTING
10	KNOB-DAMPER CONTROL
11B	WCI G000180137
11	WCI 5303208889
12	TRIM-CABINET CORNER, ALMOND
13A	241710601 Frigidaire Refrigerator Screw
13	BRACKET, TOP HINGE
14	WCI G103903
15	WCI G183861
16	WASHER, NYLON 5/16 X 5/8 (CTR & LOWER HINGE BRACKET)
17	WCI G142220
18	BRACKET, HINGE CENTER
19	SCREW, BRACKET MOUNTING (4)
20	BUTTON – DECORATIVE PLUG
21	WCI 5303001470
22	5303001321 Frigidaire Refrigerator Lower Hinge Pin
23A	TAPPING PLATE, UPPER HINGE (2) (NOT ILLUSTRATED)
23	HINGE BRACKET – BOTTOM
25	SHIM, HINGE
26	WCI G166912
27A	NUT, ANCHOR (2)
27	LEG-LEVELING (2)
28B	WCI 5303001361
28A	WCI 5308000056
28	WCI 5303001458
28C	WCI 5303207353
29	CABINET BASE
30	WCI G174747-11
32	WCI G174734
33	TUBE, INSULATION (2)
34A	5304455650 Frigidaire Refrigerator Screw
34C	WCI 5303203044
34	COVER, COIL
34B	NUT, ORIFICE (2)
35	WCI G163669
