RTG216JCD3B 02 – DOOR PARTS

RTG216JCD3B 02 – DOOR PARTS

Written by

in

RTG216JCD3B 02 – DOOR PARTS

Products

PositionProduct
*40155INSULATION-BULK (NON-ILLUSTRATED)
1GASKET-FRZR
2INTERIOR PANEL-FREEZER
3SCREW-HANDLE MTG, 8 CR TRUSS HD, 10(D) X 1/2
5WCI 5303007295
6WCI 5303007297
7218843801 Frigidaire Refrigerator Screw
8PLUG-BUTTON, ALMOND, HANDLE/DR STOP
9PLUG-BUTTON, ALMOND, HINGE BRG HOLE
10WCI 0316496
11BEARING-HINGE
12WCI 5303916698
13WCI G178500-09
14GASKET-REFRIG DOOR
15WCI 5303208886
16WCI 5303916703
17RACK-DOOR
185308000716 Frigidaire Refrigerator Dish
19215817806 Frigidaire Refrigerator Egg Tray
