RTG216JCF3A 05 – SYSTEM AND AUTOMATIC DEFROST PARTS

RTG216JCF3A 05 – SYSTEM AND AUTOMATIC DEFROST PARTS

Written by

in

RTG216JCF3A 05 – SYSTEM AND AUTOMATIC DEFROST PARTS

Products

PositionProduct
1WCI 5300163133
1AHOT TUBE REPAIR KIT-SERVICE
1B5303017691 Frigidaire Refrigerator Spacer-Tube
2BRACKET-CONDENSER MOUNTING (4)
2AWASHER
35308000039 Frigidaire Refrigerator Screw
45303305677 Frigidaire Replacement Filter Dryer Filters
5CAPACITOR
6STRAP-BALE
7HARNESS-DIVIDER (NON-ILLUSTRATED)
8HARNESS-COMPRESSOR
9CORD-ELECTRIC POWER
10WCI G183584
115304455651 Frigidaire Refrigerator Screw
125308000133 Frigidaire Refrigerator Clamp
135303001199 Frigidaire Refrigerator Wiring Harness Clamp
14240396801 Frigidaire Refrigerator Tube Clamp
15WCI 5308000728
165317842502 Frigidaire Defrost Heater
17WCI 5300162506
185308000110 Frigidaire Refrigerator Evaporator/Heater Primary Strap
19INSULATOR-EVAP
20BLOCK, EVAPORATOR, RH
21PLUG, EVAPORATOR INSULATION BLOCK, R H
22BLOCK, LEFT SIDE
235303917954 Frigidaire Refrigerator Defrost Limit Thermostat Kit
24PLATE-COMPR MTG
25218513300 Frigidaire Refrigerator Compressor Mount Grommet
26WASHER, COMPRESSOR MOUNTING (4)
27CLIP, COMPRESSOR MOUNTING (4)
28DEFROST PAN
28B5303307583 Frigidaire Refrigerator P1 Pad Noise Reduction
28ADEFROST PAN & NUT
29NUT, LOCK
30PAN RETAINER KIT-SERVICE
31WCI 3916012
32RELAY-TL
33WCI 3202863
34WCI 3202891
35WCI 08016583
