S7257^0 02 – BODY

Products

Position	Product
1	Medallion (2 Req) All 2101 Models
2	Bracket-Term. Block (2 Req) All 2101 Mod.
3	Screw 7-32×5/16“(2 Req) All 2101 Models
4	Term. Block w/Leads-All 2101 Models
5	6“ Surface Unit (Lt. Front & Rt. Rear)
6	8“ Surface Unit (Rt. Front & Lt. Rear)
7	6“ Burner Bowl (1 Req) All 2101 Models
8	8“ Burner Bowl (1 Req) All 2101 Models
9	Main Top
9	Main Top (Chrome)
11	Hinge-Main Top (Left)
11	Hinge-Main Top
11	Hinge-Main Top (Right)
12	Bracket-Hinge
13	Bottom-Burner Box
15	Extension-Burner Box Side
16	End Cap-Manifold Panel (Left)
16	End Cap
16	End Cap-Manifold Panel (Right)
17	Light-Indicator
17	Light-Indicator
17	Light-Indicator (Surface)
18	Thermostat-Oven
19	Infinite Control (Right)
20	Infinite Control (Left)
21	Insulation
23	Lens-Indicator Light
24	Panel-Control
25	WPL 78565
26	Knob-Infinite
27	Knob-Thermostat
28	Knob-Clock
29	Switch-Oven Light
30	Screw-10-32×1/2“
31	Cover-Wire
32	Screw 10-16×7/16“
33	Rod-Main Top Support
34	Clock
35	Clock Lens
36	Screw 6-32 x 5/16“
37	Bracket-Clock
