SF0105SPW0 02 – OVEN
Written by
in
SF0105SPW0 02 – OVEN
Products
Position
Product
Instructions, Installation
Diagram, Wiring
Guide, Use & Care
Diagram, Installation Instructions
List, Repair Parts
1
98005642 Whirlpool Clip
2
Gasket, Vent Deflector
4
WPW10208653 Whirlpool Insulation
7
98460 Whirlpool Nut
8
Cover, Hinge
11
Clip, Oven Bottom Plate (2)
14
Rack, Oven
15
Oven, 20“ Standard (Not Serviceable)
17
Panel, End (2) (Almond)
17
Panel, End (2) (White)
17
Panel End (2) (Platinum)
17
Panel End (2) (Toast)
18
Spring, Oven Door (2)
20
Seal, Oven Door (Side (2))
20
Seal, Oven Door (Top)
23
Screw, Leveling (4)
24
Plate, Oven Bottom
26
Front, Main
27
Back, Main
29
Base, Main
30
Deflector, Vent
33
Rod, Broiler Runner
35
Sleeve, Light Hole
36
RANGE ONLY 40W 120V APPL BULB
37
Socket, Oven Light
←
