SF318PEWZ1 01 – EXTERNAL
Written by
in
SF318PEWZ1 01 – EXTERNAL
Products
Position
Product
1
Panel, Side (2) (White)
1
Panel, Side (2) (Almond)
2
Frame, Front
3
Rail, Base (2)
4
Base, Front
5
Screw
5
Support, Main (2)
6
Support, Rear (2)
7
Screw, 10-32 X 1/2 (1)
7
WP9757891 Whirlpool Power Cord
8
Box, Flue
9
Panel, Rear
10
Burner Box
11
Safe Edge
12
Screw
12
Screw
12
Hinge, Door (2)
13
Seal, Door (2)
15
Bumper, Cooktop (2)
16
Bracket, Receptable
20
Shield, Insulation
21
Leg, Leveler
22
Nut (4)
24
WP308685 Whirlpool Microwave Screw
24
Extension, Burner
31
Anti-Tip Kit
←
WGD86HEBC0 07 – OPTIONAL PARTS (NOT INCLUDED)
LEQ8621PG2 03 – BULKHEAD PARTS, OPTIONAL PARTS (NOT INCLUDED)
→
