SF376PEWW1 06 – BACKGUARD, LITERATURE

Products

Position	Product
	List, Repair Parts
	Instructions, Installation
	Guide, Use & Care
1	Glass, Backguard
2	Trim, Backguard
3	End Cap (L.H.)
3	End Cap (R.H.)
5	Channel, Glass (2)
6	Trim, Lower
6	Panel, Control
6	Bracket, clip
11	Clock
12	Knob, Clock
13	Button. Set
14	Panel, Rear
15	Support, R.H.
15	Support L.H.
17	Shield, Heat
20	Light, Indicator (2)
21	Ballast
22	Socket, Starter
23	Starter, Fluorescent
24	Support, Lamp Socket (Left Side)
24	Support, Lamp Socket (Right Side)
26	Lampholder Fluorescent
27	Lamp, Fluorescent
