SF397PEYB0 02 – CONTROL PANEL

Products

Position	Product
1	Panel, Control (Designer White)
1	Panel, Control (White/Black/Almond)
2	Control, Electronic Timer
2	Control, Electronic Timer
3	Bracket, Timer
4	Endcap, RH
5	Endcap, LH
6	Cap, Filler
6	Cap, Filler
7	Retainer, Timer
8	Trim, Wrapper (Designer White)
8	Trim, Wrapper (White/Black/Almond)
9	Trim, Vent
9	Trim, Vent
10	Support, Control Panel (L.H.)
10	Support, Control Panel (R.H.)
11	Shield, Rear Wall
12	Deflector, Flue
13	Ballast
14	Receptacle, Fluorescent Light (RH)
14	Receptacle, Fluorescent Light (LH)
16	Trim, Canopy (White/Black/Almond)
16	Trim, Canopy (Designer White)
18	Deflector, Light
19	WP95292 Whirlpool Fluorescent Light Bulb
20	Button, Glide
21	Shield, Inner Bkgd
22	Cable, Anti-Tip
23	WP4314961 Whirlpool Lite Switch
