SHF4500W0 04 – TUB , LIT/OPTIONAL

Written by

Products

Position	Product
	Golden Harvest (Uncut)
	799344 Whirlpool Refrigerator Paint
	Almond (Uncut)
2	Snap On Panel (White)
3	Nut, 7/18-16
4	Gasket
5	Inlet, Water
6	Hose, Inlet
7	WP596669 Whirlpool Hose Clamp
8	Nut
9	Nut, Twin Spring
10	Screw, 8-18 x 5/8 (10)
11	Gasket (Alternate)
11	Gasket (Alternate)
11	Gasket (Alternate)
12	Retainer (L.H.)
12	Retainer (R.H.)
17	Shim
18	Strike
19	WP90767 Whirlpool Screw
20	WP488729 Whirlpool Refrigerator Door Screw
22	Gasket, Overflow
23	Bracket, Overflow Switch
24	Screw, 8 x 1/2 (3)
25	Float
26	Standpipe, Overflow
27	Switch, Pressure (Alternate)
27	Retainer-Main Top (2 Required)
28	Screw, 4-40 x 3/4
29	Endcap, Front or Rear (2)
30	Track (2)
31	Roller, Rack Track
46	WP308685 Whirlpool Microwave Screw
48	Screw, Shoulder (8)
49	Washer, Cup
50	Nut, Lock
51	Washer (8)
52	Washer (8)
53	Gasket, Standpipe (2)
54	350942 Whirlpool Spray Paint
54	List, Parts
54	Guide, Use & Care
54	350956 Whirlpool Spray Assembly
54	72017 Whirlpool Appliance Touch-Up Paint White
54	Instructions, Installation
54	Kit, Epoxy Patch (White)
54	WP72107 Whirlpool Touchup
54	Clip, Gasket (2)
54	72110 Whirlpool Dryer Touch-Up Paint, Golden Harvest 6 Oz
54	WPL 799351
54	Leveler (Thinner) (2oz.)
54	350930 Whirlpool White Spray Paint
54	Golden Harvest
54	Harness, Wiring
