SHU40011 02 – TUB , NOT ILLUSTRATED

SHU40011 02 – TUB , NOT ILLUSTRATED

Written by

in

SHU40011 02 – TUB , NOT ILLUSTRATED

Products

PositionProduct
Golden Harvest (Uncut)
799344 Whirlpool Refrigerator Paint
Enamel, New Avocado (1 Qt. Uncut)
Enamel, Coffee (1 Qt. Uncut)
Enamel, Black (1 Qt. Uncut)
1Bracket, Mounting (2)
2Snap On Panel (White)
3WPW10144763 Whirlpool Tie Wire
4Inlet, Water
5Hose, Inlet
6WP596669 Whirlpool Hose Clamp
7WP356138 Whirlpool Hose Clamp
8675544 Whirlpool Drain Hose
10Brace
11Leg & Hinge Assembly, (L.H.)
11Leg & Hinge Assembly, (R.H.)
12Screw, 8-32 x 3/8 Hex Washer Head Slotted Tapping Ground (1)
14Relief, Strain
15Nut, 7/18-16
16Gasket
17Nut
18Bracket, Overflow Switch
19Screw, 8 x 1/2 (3)
20Gasket (Alternate)
20Gasket (Alternate)
21Retainer (L.H.)
21Retainer (R.H.)
22Retainer-Main Top (2 Required)
22Switch, Pressure (Alternate)
23Screw, Leveling
26Valve, Water Inlet (Alternate)
28300068 Whirlpool Dishwasher Cover Assembly
30Nut, Twin Spring
34Nut, Lock
35Washer (8)
37WP488729 Whirlpool Refrigerator Door Screw
38Float
39Standpipe, Overflow
40Gasket, Overflow
41Screw, 4-40 x 3/4
44Shim
45Strike
46WP308685 Whirlpool Microwave Screw
47Washer (8)
48Washer, Cup
49Roller, Rack Track
50Screw, Shoulder (8)
51Track (2)
52Endcap, Front or Rear (2)
53Screw, 8-18 x 5/8 (10)
54Gasket, Standpipe (2)
55WPL 301656
56WP90767 Whirlpool Screw
57Clip, Gasket (2)
60350956 Whirlpool Spray Assembly
60350930 Whirlpool White Spray Paint
60WPL 302628
6072110 Whirlpool Dryer Touch-Up Paint, Golden Harvest 6 Oz
60Tag, Energy Fact
60WPL 302080
60WP72107 Whirlpool Touchup
6072017 Whirlpool Appliance Touch-Up Paint White
60Golden Harvest
60350942 Whirlpool Spray Paint
60285006 Whirlpool Spray
60Kit, Epoxy Patch (White)
60W11086533 Whirlpool Dishwasher Shield
60WPL 799351
60Leveler (Thinner) (2oz.)
60Paint, Spray 13 Oz. (Avocado)
60paint, spray 13 oz. (coffee)
60Paint, Touch-Up 1/2 Oz. (Coffee)
6072109 Whirlpool Dacor Avocado Touch-Up Paint
6072032 Whirlpool Touch Up Paint Black
60WPL 302665
