SM230PXD1 03 – CONSOLE, CONTROL AND DRUM

Products

Position	Product
*63546	RESISTOR
*63546	Spacer,washer ,timer shaft
*63546	REGISTER
*63546	WCI 5303208455
*63547	5303303590 Frigidaire Dryer 4.0" Cable Tie
*63546	WCI 08008454
1	WCI 3205944
2	WCI 5303209765
4	WCI 5303283043
5	WCI F144068-000
6	WCI 5303283044
7	WCI 5303283045
8	WCI 5303283046
10	WCI 3204999
11	131205100 Frigidaire Screw
12	WCI 3205000
13	WCI 08011280
14	WCI 5303285467
15	WCI 3205947
17	WCI 3205948
18	PANEL – CONTROL
20	WCI 3205006
21	216858001 Frigidaire Refrigerator Screw
22	KNOB & DIAL ASSY
24	WCI 3205008
25	WCI 5303937088
26	BAFFLE-DRUM (3)
27	WCI 3205010
31A	WCI 5303161081
31	WCI 5303161080
32	WCI 5308004076
33	SNAP RING (4)
34	WCI 08012152
35	WCI 08004077
36	WCI 5303209445
37	WCI 5303288388
38	GUIDE (2)
39	COVER-LINT HSG
40	SCREW (2)
41	WCI 3205015
42	WCI 5303208454
44	WCI 08010804
46	WCI 08001544
47	WCI 3205016
48	WCI 3205017
50	WCI 3205018
