SSX130EM1W 03 – CABINET PARTS

Products

Position	Product
1	TRIM (4)
2	BRACKET, TOP HINGE
3	WCI G103903
4	WCI G183861
5	241710601 Frigidaire Refrigerator Screw
6	COVER HINGE, WHITE
7	WCI G174747–01
8	TUBE, INSULATION (2)
9	WCI G174733
10	WCI G174734
11	WCI G177673
12	PAN, STORAGE
13	BASE-CABINET
14	TAPPING, PLATE (2)
15	NUT, ANCHOR (2)
16	LEG-LEVELING (2)
17	WCI G166912
18	BRACKET, HINGE, LOWER
20	SHIM, HINGE
21	WASHER, NYLON 5/16 X 5/8 (CTR & LOWER HINGE BRACKET)
22	5303001321 Frigidaire Refrigerator Lower Hinge Pin
23	215667501 Frigidaire Refrigerator Ice Tray Primary
24	CLIP-CANOE (2) (NON-ILLUSTRATED)
25	WCI G179612
26	LABEL-BAFFLE (NON-ILLUSTRATED)
27	DRIP TRAY
28	SUPPORT-TRAY RH
29	5304455650 Frigidaire Refrigerator Screw
30	GASKET-TRAY (NON-ILLUSTRATED)
31	STOPPER-RUBBER
32	316538904 Frigidaire Oven Lamp Light
33	SOCKET LIGHT
34	BRACKET-CONTROL
35	5304455852 Frigidaire Refrigerator Screw
36	WCI 3016543
37	WCI G162205-08
38	WCI G107080
39	5309918806 Frigidaire Refrigerator Light Switch Door
40	WCI 3016544
41	SCREW-GROUND (2) (NON-ILLUSTRATED)
42	WCI G172172-01
43	COVER-CRISPER
