TAK160EN0F 03 – CABINET PARTS

Products

Position	Product
*84546	BUTTON, LINER
1	WCI 3015421
2	KNOB-DAMPER CONTROL
3	NUT, DAMPER MOUNTING
4	DAMPER FAN COVER
5	5308000010 Frigidaire Refrigerator Evaporator Fan Blade
7	RING, FAN ORIFICE
8	G187559 Frigidaire Refrigerator Bushing
9	WCI G185302
10A	5304455650 Frigidaire Refrigerator Screw
10	COVER-COIL
10B	NUT, ORIFICE (2)
11	PLUG-SHORT TEST HOLE (NON-ILLUSTRATED)
12	BUTTON DECORATIVE PLUG
13	5300158289 Frigidaire Evaporator Fan Motor
14	WCI G185303
15	WCI G164571
16	5304455651 Frigidaire Refrigerator Screw
17	TROUGH-DRAIN
18	WCI G163669
19	TUBE, INSULATION (2)
20	WCI G174733
21	WCI G174734
22	WCI G174747-10
23	TUBE, DRAIN
24	RING, SEAL (NON-ILLUSTRATED)
25A	PIN PUSH SPOUT (2)
25	SPOUT DRAIN TUBE
26	CABINET BASE
27	LEG-LEVELING (2)
28	NUT, ANCHOR (2)
29	WCI G166912
30	HINGE-BRACKET-BOTTOM
31A	TAPPING, PLATE (2)
31	SHIM, HINGE
32	5303001321 Frigidaire Refrigerator Lower Hinge Pin
33	WCI G103903
34	WASHER, NYLON 5/16 X 5/8 (CTR & LOWER HINGE BRACKET)
35	BRACKET, HINGE CENTER
35A	SCREW, BRACKET MOUNTING (4)
35B	WASHER (2)
36	WCI G142220
37	WCI 3202339
38	BRACKET, TOP HINGE
38B	TAPPING PLATE (2)
38A	241710601 Frigidaire Refrigerator Screw
39	WCI G183861
40	COVER HINGE, COFFEE
