TAK160EN0F 04 – SHELVES AND SUPPORTS

Products

Position	Product
1	WCI 3916133
2	SCREW, BRACKET MOUNTING (4)
3	WASHER (2)
4	HTR, CENTER RAIL
5	SPACER (NON-ILLUSTRATED)
6	CLAMP, MULLION MOUNTING
7	BOTTOM, FC
8	DIVIDER, CENTER
8A	HARNESS, WIRING
9	TOP-REFRIGERATOR
9A	SCREW (5)
10	DEFLECTOR AIR
11	WCI G162178
12	5309918806 Frigidaire Refrigerator Light Switch Door
13A	LABEL-CONTROL BOX
13	WCI G176722-05
13B	5304455650 Frigidaire Refrigerator Screw
14	KNOB
15	SWITCH SLIDE
16	TUBE
17	WCI 3200810
17A	WCI G107080
18	215846602 Frigidaire Refrigerator 8-Hour Defrost Timer
18A	5304455649 Frigidaire Refrigerator Screw
19	SOCKET LIGHT
20	316538904 Frigidaire Oven Lamp Light
21	215667501 Frigidaire Refrigerator Ice Tray Primary
22	WCI G178511-01
23	WCI G490016-03
24	SUPPORT, CRISPER COVER
25	WCI 3205335
26	WCI 3205338
27	WCI G177106-03
