TAK160EN0W 02 – DOOR PARTS

Products

Position	Product
1	GASKET-FREEZER
2	218730603 Frigidaire Door Gasket
3	INNER PANEL
4	WCI 3016153
5	SUPPORT RS (3)
6	SUPPORT LS (3)
7	DOOR, DAIRY
8	WCI 3016152
9	INNER PANEL
9A	5304455651 Frigidaire Refrigerator Screw
10	WCI G169332-01
11	WCI 3916293
12	BEARING, HINGE (3)
13	NAMEPLATE-ASSY
14	240494001 Frigidaire Refrigerator Plug Button
15	REFR DOOR-WHITE
16	WCI G89643
17	WCI G189451-01
18	WCI 3201377
18A	TRIM INSERT-GRIP (2) (NON-ILLUSTRATED)
19	END-HANDLE (2)
20	WCI G189452-01
21	WCI G185566
22	WCI G189468-12
