TEDL640AN0 02 – SECTION

Products

PositionProduct
350930 Whirlpool White Spray Paint
Dryer
Almond (Uncut)
Leveler (Thinner)
List, Service Parts
WP72107 Whirlpool Touchup
Instructions, Installation
799344 Whirlpool Refrigerator Paint
Use & Care Guide
72017 Whirlpool Appliance Touch-Up Paint White
350956 Whirlpool Spray Assembly
350938 Whirlpool Spray Gun
1Panel, Rear Console
3WPW10139210 Whirlpool Screw
4Cap, End (L.H.)
5Clip, Retainer
6WP388326 Whirlpool Screw
78283286 Whirlpool Wire Harness
8Cap, End (R.H.)
10339392V Whirlpool Dryer Lint Filter Screen
11Cover, Lint Screen (Almond)
11Cover, Lint Screen (White)
12WPW10044480 Whirlpool Hinge Assembly
12WPW10044470 Whirlpool Hinge Assembly
13W11693756 Whirlpool Screw Assembly
14WP489069 Whirlpool Compactor Screw
15WP693995 Whirlpool Screw
16Top (Almond)
16Top (White)
17WP688805 Whirlpool Spring Clip
18Knob, Control (For Almond Model)
21WP3396215 Whirlpool Timer
30WP357213 Whirlpool Hinge Stopper
31Harness, Wiring
39(Alt.)
39Switch, Push-To-Start
48Timer Knob Assembly
53Bracket, Control
54Panel, Control
67WP689559 Whirlpool Nut
72Wire, Ground
79Switch, Temperature
81Button, Push-To-Start
