TGB504CFB3 04 – BODY

TGB504CFB3 04 – BODY

Written by

in

TGB504CFB3 04 – BODY

Products

PositionProduct
*64446WCI 5304400428
*64447SCREW (8-18 X 1 )
*644445303211311 Frigidaire Refrigerator Screw
*644495304453707 Frigidaire Oven Screw
*64448216858001 Frigidaire Refrigerator Screw
3WCI 5303317132
6WCI 08012158
7WCI 5303298313
7Hinge Assy,LH lower
8WCI 318136500
9WCI 5303317977
10WCI 5303317976
14SOCKET-LIGHT/LAMP, OVEN
15316538904 Frigidaire Oven Lamp Light
25WCI 5303317712
275303284616 Frigidaire Range Bulb Clip Thermostat
29GLIDE-BROILER RACK
33WCI 5303317128
36FLUE
395304515659 Frigidaire Oven Power Cord
56WCI 318028200
58WCI 5304400183
58WCI 5304400184
83WCI 318109510
85SLEEVE-SPRING (2)
85SPRING-OVEN DOOR,UPPER
85WCI 5303317126
85WCI 5303317711
85WCI 318113300
97WCI 5303317130
98TRIM-BODYSIDE,LH
98TRIM-BODYSIDE,RH
121WCI 5303317131
124WCI 318076801
130WCI 318034600
136WCI 5303317129
158ASEAL-DOOR,BLACK ,TOP BROILER
158BSEAL-SIDE,BAKE OVEN
216CAP-END BOTTOM,LH
216WCI 318034502
216WCI 318034503
216CAP-END BOTTOM,RH
242TRIM CENTER
243WCI 3201495
244BWCI 8014383
244AHinge Assy,oven door ,RH upper
246WCI 318133600
247GLIDE-OVEN RACK
248WCI 5303317121
249WCI 5304400385
250WCI 318106003
251WCI 318106004
