TGDL200AN0 02 – TOP AND CABINET, LIT/OPTIONAL

Products

Position	Product
	350930 Whirlpool White Spray Paint
	Almond (Uncut)
	Instructions, Installation
	List, Service Parts
	WP72107 Whirlpool Touchup
	Washer (Belt Drive)
	799344 Whirlpool Refrigerator Paint
	Leveler (Thinner)
	72017 Whirlpool Appliance Touch-Up Paint White
	350956 Whirlpool Spray Assembly
	350938 Whirlpool Spray Gun
	Use & Care Guide
	Dryer
1	Panel, Rear Console
2	WP489069 Whirlpool Compactor Screw
4	Cap, End (L.H.)
5	WP688805 Whirlpool Spring Clip
6	Cap, End (R.H.)
7	Clip, Retainer
10	339392V Whirlpool Dryer Lint Filter Screen
11	Cover, Lint Screen (White)
11	Cover, Lint Screen (Almond)
12	WPW10044470 Whirlpool Hinge Assembly
12	WPW10044480 Whirlpool Hinge Assembly
13	W11693756 Whirlpool Screw Assembly
14	WP388326 Whirlpool Screw
16	Top (Almond)
16	Top (White)
18	WP94614 Whirlpool Terminal
21	WP3396215 Whirlpool Timer
29	WP3390631 Whirlpool Screw
30	Harness, Wiring
31	WPW10139210 Whirlpool Screw
39	(Alt.)
39	Switch, Push-To-Start (Alternate)
39	Switch, Push-To-Start
48	Timer Knob Assembly
53	Bracket, Control
54	Panel, Control
67	WP689559 Whirlpool Nut
72	Wire, Ground
75	353424 Whirlpool Connector
75	Receptacle, 3-Way Terminal (Use W/94614)
81	Knob, Push-To-Start
82	WP357213 Whirlpool Hinge Stopper
84	WP596797 Whirlpool Terminal
