| NI | NUT, SUPPORT OVN VLV (NOT ILLUSTRATED) |
| 1 | Manifold |
| 2 | WCI 318087100 |
| 3 | WCI 318232608 |
| 8 | 5304518635 Frigidaire Oven Module |
| 10A | Burner,top ,rear |
| 10 | BURNER-TOP, FRONT |
| 11No. | WCI 318148504 |
| 11A | WCI 318083201 |
| 12 | RETAINER-IGNITER |
| 14 | 5308007974 Frigidaire Pressure Regulator |
| 17 | WCI 318087200 |
| 18 | WCI 5303202752 |
| 19 | 5303935066 Frigidaire Oven Flat Igniter 17" Leads |
| 20 | WCI 3203676 |
| 21 | 5303013272 Frigidaire Oven Nut |
| 28 | WCI 318087400 |
| 33 | WCI 5303210471 |
| 36 | WCI 318249303 |
| 49 | SUPPORT-OVEN SAFETY VALVE |
| 55 | WCI 5303324193 |
| 70 | COVER - OVEN SAFETY VALVE |
| 72 | WCI 5303323141 |
