TGK160AN6V 04 – SHELVES AND SUPPORTS

Products

Position	Product
*13445	HARNESS, WIRING
1	WCI G178303-06
2	WCI G161013-54
3	COVER-CRISPER
4	SUPPORT, CRISPER COVER
5	WCI G171608-11
6	WCI G172434-25
7	WCI G172436-05
8	WCI G171654-34
9	WCI G174655-15
9A	5304455650 Frigidaire Refrigerator Screw
10	CONTROL
10A	WCI G107080
11	TUBE
12A	5304455649 Frigidaire Refrigerator Screw
12	215846602 Frigidaire Refrigerator 8-Hour Defrost Timer
13	316538904 Frigidaire Oven Lamp Light
14	SOCKET LIGHT
15	WCI G178294-01
16	KNOB CONTROL
17	SWITCH SLIDE
18	MULLION, AVOCADO
19	SCREW, BRACKET MOUNTING (4)
20	CLAMP, MULLION MOUNTING
21	WASHER (2)
22	SPACER, MULLION (2)
23	HTR, CENTER RAIL
24	5309918806 Frigidaire Refrigerator Light Switch Door
25A	SCREW (5)
25	TOP PC
26	DIVIDER, CENTER
27	BOTTOM, FC
