TGK180EN0W 04 – SHELVES AND SUPPORTS

Products

PositionProduct
*42378SCREW (5)
*42379HARNESS, WIRING
1PAN-CRISPER
2TRIM (2)
3PAN-CRISPER
4SUPPORT, CRISPER COVER
5AGASKET COVER (NON-ILLUSTRATED)
5COVER-CRISPER
6FRAME, SHELF (3)
7WCI 3015066
8WCI G172434-08
9WCI G172436-05
10316538904 Frigidaire Oven Lamp Light
11KNOB
12215846602 Frigidaire Refrigerator 8-Hour Defrost Timer
135304455649 Frigidaire Refrigerator Screw
14TUBE
15COLD CONTROL
15AWCI G107080
16SOCKET LIGHT
17WCI G176722-03
18LABEL
19SWITCH SLIDE
20SPACER, MULLION (2)
21WCI G168722
22MULLION, WHITE
23STRAP, MULLION MOUNTING
245309918806 Frigidaire Refrigerator Light Switch Door
25DIVIDER, CENTER
26BOTTOM, FC
27TOP-REFRIGERATOR
28SCREW, BRACKET MOUNTING (4)
