TGK180EN1F 02 – DOOR PARTS

Products

Position	Product
1	WCI 3916271
2	WCI G169332-10
3	NAMEPLATE FRAME
3A	TAPE-FRAME MOUNTING (NON-ILLUSTRATED)
4	LABEL-NAMEPLATE
5	WCI G162977-10
6	REFR DOOR (COFFEE)
6A	BEARING, HINGE (3)
7A	STOP, DOOR. PC & FC (2)
8	WCI G89643
9	TRIM-REFRIGERATOR DOOR
10	GASKET
11	INNER PANEL
12	WCI 3015061
13	SUPPORT RS (3)
14	SUPPORT LS (3)
15	DOOR, DAIRY
16	WCI 3015603
17	WCI 3015060
18	WCI 3015063
18A	TAPE-FRAME MOUNTING (NON-ILLUSTRATED)
19	INNER PANEL
19A	5304455651 Frigidaire Refrigerator Screw
20	GASKET
21	WCI G189451-01
22A	TRIM INSERT-GRIP (2) (NON-ILLUSTRATED)
22	WCI 3201377
23	END-HANDLE (2)
24	WCI G189452-01
25	WCI G185566
