TGK180EN1W 02 – DOOR PARTS

TGK180EN1W 02 – DOOR PARTS

Written by

in

TGK180EN1W 02 – DOOR PARTS

Products

PositionProduct
1WCI 3916268
2WCI G169332-01
3ATAPE-FRAME MOUNTING (NON-ILLUSTRATED)
3NAMEPLATE FRAME
4LABEL-NAMEPLATE
5240494001 Frigidaire Refrigerator Plug Button
6ABEARING, HINGE (3)
6REFR DOOR (WHITE)
7ASTOP, DOOR. PC & FC (2)
8WCI G89643
9TRIM-REFRIGERATOR DOOR
10GASKET
11INNER PANEL
12WCI 3015061
13SUPPORT RS (3)
14SUPPORT LS (3)
15DOOR, DAIRY
16WCI 3015603
17WCI 3015060
18WCI 3015063
18ATAPE-FRAME MOUNTING (NON-ILLUSTRATED)
19A5304455651 Frigidaire Refrigerator Screw
19INNER PANEL
20GASKET
21WCI G189451-01
22ATRIM INSERT-GRIP (2) (NON-ILLUSTRATED)
22WCI 3201377
23END-HANDLE (2)
24WCI G189452-01
25WCI G185566
