TGK180EN2W 04 – SHELVES AND SUPPORTS

TGK180EN2W 04 – SHELVES AND SUPPORTS

Written by

in

TGK180EN2W 04 – SHELVES AND SUPPORTS

Products

PositionProduct
1BOTTOM, FC
2DIVIDER, CENTER
2AHARNESS, WIRING
3TOP-REFRIGERATOR
3ASCREW (5)
4DEFLECTOR AIR
5WCI G162178
65309918806 Frigidaire Refrigerator Light Switch Door
7STRAP, MULLION MOUNTING
8SPACER (NON-ILLUSTRATED)
9WCI 3018916
10WCI 3200366
11WASHER (2)
12SCREW-10-24 X 7/8 (4)
13KNOB
14B5304455650 Frigidaire Refrigerator Screw
14WCI G176722-03
14ALABEL
15SWITCH SLIDE
16TUBE
17WCI 3200810
17AWCI G107080
18215846602 Frigidaire Refrigerator 8-Hour Defrost Timer
18A5304455649 Frigidaire Refrigerator Screw
19SOCKET LIGHT
20316538904 Frigidaire Oven Lamp Light
21WCI G177059-02
22WCI G166495-01
23TRIM, SHELF, FREEZER
24215667501 Frigidaire Refrigerator Ice Tray Primary
25FRAME, SHELF (3)
26WCI 3015066
27TRIM-SHELF FRONT (3)
28TRIM-REAR
29GASKET COVER (NON-ILLUSTRATED)
31PAN-CRISPER
32PAN-CRISPER
33TRIM (2)
34SUPPORT, CRISPER COVER
