TMK180EN0T 03 – CABINET PARTS

Products

Position	Product
*12088	215667501 Frigidaire Refrigerator Ice Tray Primary
*12090	COVER HINGE, WHEAT
*12089	TAPPING PLATE (2)
*12087	WCI G161015-17
1	WCI G185303
2	G187559 Frigidaire Refrigerator Bushing
3	5300158289 Frigidaire Evaporator Fan Motor
4	WCI G177529
5	WCI G185302
6	RING, FAN ORIFICE
7	5308000010 Frigidaire Refrigerator Evaporator Fan Blade
8	WCI G163061-76
9A	NUT, DAMPER MOUNTING
9	WCI G162747-22
10	DAMPER FAN COVER
11	BUTTON DECORATIVE PLUG
12	WCI G177534
13	RING, SEAL (NON-ILLUSTRATED)
14	TUBE, DRAIN
15	SPOUT DRAIN TUBE
16	TUBE, INSULATION (2)
17	WCI G163669
18	WCI G183861
19A	WASHER, NYLON 5/16 X 5/8 (CTR & LOWER HINGE BRACKET)
19A	WCI G103903
19	BRACKET, TOP HINGE
20	WCI G179684-09
21	WCI G142220
22A	SCREW, BRACKET MOUNTING (4)
22	BRACKET, HINGE CENTER
23	WCI G162178
24A	WCI G189341
24	CHANNEL, SHELF (2)
25	5304455852 Frigidaire Refrigerator Screw
26	BRACKET-HINGE
27	5303001321 Frigidaire Refrigerator Lower Hinge Pin
28	SHIM, HINGE
28A	241710601 Frigidaire Refrigerator Screw
29	WCI G166912
30B	BOLT-ROLLER (2)
30	ROLLER FRONT, ADJUSTABLE (2)
30A	SPRING-ROLLER (2)
30C	SUPPORT, ROLLER (2)
31	ROLLER, REAR (2)
31A	BOLT ROLLER (2)
32	DEFLECTOR AIR
33	WCI G174733
34	WCI G174734
35	WCI G174747-09
