TSI206EN1F 05 – SYSTEM AND AUTOMATIC DEFROST PARTS

Products

Position	Product
*83837	HOT TUBE REPAIR KIT
*83837	5303307583 Frigidaire Refrigerator P1 Pad Noise Reduction
1	5303305677 Frigidaire Replacement Filter Dryer Filters
2	WCI G163133
3	BRACKET-CONDENSER MOUNTING (4)
4	5303006412 Frigidaire Refrigerator Cover Mounting Strap
6	HARNESS-DIVIDER (NON-ILLUSTRATED)
7	HARNESS-COMPRESSOR
8	CORD, SERVICE
9	CLIP, COMPRESSOR MOUNTING (4)
10	WASHER, COMPRESSOR MOUNTING (4)
11	218513300 Frigidaire Refrigerator Compressor Mount Grommet
12A	NUT, LOCK
12	DEFROST PAN & NUT
13	WCI G182225-18
14	COMPR W/ ELECT
15	WCI G189006
16	CAPACITOR-RUN
17	STRAP-CAPACITOR
18	240396801 Frigidaire Refrigerator Tube Clamp
19	PLATE
20	BLOCK, LEFT SIDE
21	BLOCK, EVAPORATOR, RH
22	PLUG, EVAPORATOR INSULATION BLOCK, R H
23	5303917954 Frigidaire Refrigerator Defrost Limit Thermostat Kit
24	EVAPORATOR
25	5308000110 Frigidaire Refrigerator Evaporator/Heater Primary Strap
26	WCI 08000728
27	5317842502 Frigidaire Defrost Heater
28	INSULATOR
29	WCI G183584
31	5304455651 Frigidaire Refrigerator Screw
31A	5308000039 Frigidaire Refrigerator Screw
32	5303001199 Frigidaire Refrigerator Wiring Harness Clamp
33	PAN RETAINER KIT-SERVICE
