TSI206EN1V 04 – SHELVES AND SUPPORTS

Products

Position	Product
1	WCI 3016529
2	WCI 3016531
3	WCI 3016530
4	TRIM-SMALL PAN
5	COVER-PAN
6	GASKET, COVER
7	WCI 3016528
8	WCI 3015333
9	WCI G161013-67
10	WCI G177106-01
11	WCI G177390-23
12	WCI G172434-09
13	WCI 3015157
14	WCI G172434-08
15	SHELF-FREEZER
16	WCI G172434-34
17	END CAP-SHELF,PROTECTOR
18	WCI G176722-03
18A	5304455650 Frigidaire Refrigerator Screw
19A	WCI G107080
19	WCI 3200810
20	TUBE
21A	5304455649 Frigidaire Refrigerator Screw
21	215846602 Frigidaire Refrigerator 8-Hour Defrost Timer
22	316538904 Frigidaire Oven Lamp Light
23	SOCKET LIGHT
24	KNOB
25	SWITCH SLIDE
26	LABEL
27	MULLION-AVOC
28	SCREW, BRACKET MOUNTING (4)
29	STRAP, MULLION MOUNTING
30	WASHER (2)
31	SPACER (NON-ILLUSTRATED)
32	WCI G177254
33	5309918806 Frigidaire Refrigerator Light Switch Door
34A	SCREW (5)
34	TOP-REFRIGERATOR
35	WCI G184683
36	WCI G184604
