TSK180EN1F 04 – SHELVES AND SUPPORTSadmin2025-04-26T09:49:14+00:00TSK180EN1F 04 – SHELVES AND SUPPORTS
Products
| Position | Product |
|---|
| 1 | BOTTOM, FC |
| 2A | HARNESS, WIRING |
| 2 | DIVIDER, CENTER |
| 3A | SCREW (5) |
| 3 | TOP-REFRIGERATOR |
| 4 | DEFLECTOR AIR |
| 5 | WCI G162178 |
| 6 | 5309918806 Frigidaire Refrigerator Light Switch Door |
| 7 | STRAP, MULLION MOUNTING |
| 8 | SPACER (NON-ILLUSTRATED) |
| 9 | WCI 3018916 |
| 10 | WCI 3200369 |
| 11 | WASHER (2) |
| 12 | SCREW, BRACKET MOUNTING (4) |
| 13 | KNOB |
| 14B | 5304455650 Frigidaire Refrigerator Screw |
| 14 | WCI G176722-03 |
| 14A | LABEL |
| 15 | SWITCH SLIDE |
| 16 | TUBE |
| 17A | WCI G107080 |
| 17 | WCI 3200810 |
| 18 | 215846602 Frigidaire Refrigerator 8-Hour Defrost Timer |
| 18A | 5304455649 Frigidaire Refrigerator Screw |
| 19 | SOCKET LIGHT |
| 20 | 316538904 Frigidaire Oven Lamp Light |
| 21 | WCI G177059-02 |
| 22 | WCI G166495-01 |
| 23 | TRIM, SHELF, FREEZER |
| 24 | 215667501 Frigidaire Refrigerator Ice Tray Primary |
| 25 | WCI G177390-03 |
| 26 | TRIM, SHELF, FRONT, 13-7/16`` (4) |
| 27 | WCI G177106-01 |
| 28 | WCI G177623-06 |
| 29 | WCI G161013-67 |
| 30 | SHELF FULL |
| 31 | TRIM-SHELF FRONT (3) |
| 32 | COVER-CRISPER |
| 33 | GASKET COVER (NON-ILLUSTRATED) |
| 34 | PAN-CRISPER |
| 35 | PAN-CRISPER |
| 36 | TRIM (2) |
| 37 | SUPPORT, CRISPER COVER |
