TSX120EN0F 05 – SYSTEM AND AUTOMATIC DEFROST PARTS

Products

PositionProduct
*17127HARNESS-COMPRESSOR
*17125HOT TUBE REPAIR KIT (NON-ILLUSTRATED)
15303917954 Frigidaire Refrigerator Defrost Limit Thermostat Kit
2BLOCK, EVAPORATOR, RH
3BRACKET-CONDENSER MOUNTING (4)
4WCI G164924
6WCI G149013
75308000039 Frigidaire Refrigerator Screw
85303001199 Frigidaire Refrigerator Wiring Harness Clamp
95303305677 Frigidaire Replacement Filter Dryer Filters
10CORD, SERVICE
11CLIP, COMPRESSOR MOUNTING (4)
12WASHER, COMPRESSOR MOUNTING (4)
13218513300 Frigidaire Refrigerator Compressor Mount Grommet
14WCI G188885-01
15STRAP-CAPACITOR
165303006412 Frigidaire Refrigerator Cover Mounting Strap
18RETAINER, OVERLOAD
19WCI G162822
20WCI G188877
21WCI G182225-18
22WCI G190360
23DEFROST PAN & NUT
24NUT, LOCK
25BLOCK, LEFT SIDE
26STRAP-ALUMINUM (2)
27WCI G162432-01
28EVAPORATOR
29INSULATOR-EVAPORATOR
