UXT5230BDS2 02 – HOOD PARTS

UXT5230BDS2 02 – HOOD PARTS

Written by

in

UXT5230BDS2 02 – HOOD PARTS

Products

PositionProduct
1USE AND CARE GUIDE
2WPW10419516-includeCORE Whirlpool WPW10419516 Refrigerator Electronic Control Board + Core
3W10416841 Whirlpool Filter Latch
4W10416838 Whirlpool Cover Assembly
5WPW10638164 Whirlpool Light Bulb
6W10416839 Whirlpool Fan Motor Assembly
7W11516461 Whirlpool Hood Damper
8BULB-LIGHT
9W11177751 Whirlpool Grease Filter
10W10862083 Whirlpool Capacitor
11W10416840 Whirlpool Fan Blade
12W10416843 Whirlpool Bottom Panel
12AW10419535 Whirlpool Bottom Panel
13W10416844 Whirlpool Bottom Panel
13AW10419532 Whirlpool Bottom Panel
14W11176975 Whirlpool Hardware Assembly
