W5TXEWFWQ01 02 – DOOR PARTS

W5TXEWFWQ01 02 – DOOR PARTS

Written by

in

W5TXEWFWQ01 02 – DOOR PARTS

Products

PositionProduct
1REFRIGERATOR DOOR (INCLUDES ITEMS 7 & 10) (BLACK)
1LW10287865 Whirlpool Refrigerator DOR-FIP BT
1REFRIGERATOR DOOR (INCLUDES ITEMS 7 & 10) (WHITE)
2WP2326169B Whirlpool Refrigerator Handle
2HANDLE
2WP2221946T Whirlpool Refrigerator Handle
3WP8281206 Whirlpool Refrigerator Screw
4WP489357 Whirlpool Recessed Screw
5WP2258681W Whirlpool Refrigerator Shim
52258681B Whirlpool Refrigerator Shim
6WP2202819B Whirlpool Refrigerator Cover
6Cover, Screw (Biscuit)
6WP2202819W Whirlpool Refrigerator Cover
7WP2319265T Whirlpool Refrigerator FIP Gasket
72319265B Whirlpool Refrigerator FIP Gasket
8WP2213265 Whirlpool Refrigerator Nameplate
9W11129820 Whirlpool Refrigerator Door Trim
10WP2183003 Whirlpool Thimble
11WP2266727 Whirlpool Refrigerator Door Trim
12LW10287866 Whirlpool FIP Door Bottom
12FREEZER DOORN (INCLUDES ITEMS 10 & 14) (WHITE)
12FREEZER DOORN (INCLUDES ITEMS 10 & 14) (BLACK)
13WP2189000 Whirlpool Refrigerator Handle Plug
13WP2189009 Whirlpool Refrigerator Handle Plug
13WP2200936 Whirlpool Refrigerator Handle Plug
14WP2319263B Whirlpool Refrigerator Black Door Gasket
14WP2319263T Whirlpool Refrigerator FIP Gasket
15WP2266738 Whirlpool Refrigerator Door Trim
16W11745278 Whirlpool Bracket
17WP488921 Whirlpool Refrigerator Screw
18WP2212648 Whirlpool Refrigerator Hinge Sleeve Hole Plug
18WP2212649 Whirlpool Refrigerator Button Plug
18WP2212651 Whirlpool Refrigerator Button Plug
19WP2156003 Whirlpool Refrigerator Door Shelf End Cap
202202098B Whirlpool Refrigerator Handle
20HANDLE
20WP2215015 Whirlpool Refrigerator Handle
21ENDCAP
