W8RXDGFXS00 02 – DOOR PARTS

W8RXDGFXS00 02 – DOOR PARTS

Written by

in

W8RXDGFXS00 02 – DOOR PARTS

Products

PositionProduct
1REFRIGERATOR DOOR PANEL (INCLUDES ILLUS. 9 & MOLDED DOOR HANDLE) (BLACK)
1REFRIGERATOR DOOR PANEL (INCLUDES ILLUS. 9 & MOLDED DOOR HANDLE) (WHITE)
1REFRIGERATOR DOOR PANEL (INCLUDES ILLUS. 9 & MOLDED DOOR HANDLE) (STAINLESS STEEL)
2SCREW
32258681B Whirlpool Refrigerator Shim
3WP2258681W Whirlpool Refrigerator Shim
4W11396038 Whirlpool Door Shelf Bin
52265645W Whirlpool Refrigerator Handle
5Endcap, Handle (Refrigerator)
6ENDCAP, BOTTOM (WHITE)
6ENDCAP, BOTTOM (BLACK)
7ENDCAP, BOTTOM (WHITE)
7ENDCAP, BOTTOM (BLACK)
8Door, Compartment
9WP2319264B Whirlpool Door Gasket
9WP2319264W Whirlpool Refrigerator FIP Gasket
102264477 Whirlpool Refrigerator Housing Assembly
11WP2213265 Whirlpool Refrigerator Nameplate
12WPW10234241 Whirlpool Door Shelf Trim
13FREEZER DOOR PANEL (INCLUDES ILLUS. 14 & MOLDED DOOR HANDLE) (WHITE)
13FREEZER DOOR PANEL (INCLUDES ILLUS. 14 & MOLDED DOOR HANDLE) (STAINLESS STEEL)
13FREEZER DOOR PANEL (INCLUDES ILLUS. 14 & MOLDED DOOR HANDLE) (BLACK)
14GASKET-FIP
14WP2319263B Whirlpool Refrigerator Black Door Gasket
15WPW10468559 Whirlpool Refrigerator Clear Door Shelf Trim
16W11745278 Whirlpool Bracket
17WP2212651 Whirlpool Refrigerator Button Plug
17WP2212648 Whirlpool Refrigerator Hinge Sleeve Hole Plug
182252863 Whirlpool Refrigerator Door Trim
182265644W Whirlpool Refrigerator Door Trim
19WP2266727 Whirlpool Refrigerator Door Trim
20WP2156003 Whirlpool Refrigerator Door Shelf End Cap
