WA24F4DTFB 02 – CONSOLE AND CONTROL PARTS

Products

Position	Product
*39801	WCI F140886-000
*39804	LID INSTRUCTION
*39800	LAUNDRY GUIDE
*39804	WCI F141707-000
*39806	WCI F078621-000
*39802	WCI F140489-000
1	WCI F140485-000
2	134154100 Frigidaire Screw 10-32 x 0.375 Co
3	SPEED CLIP, PRESSURE HOSE TO CABINET (2)
4	WCI F140881-000
5	WCI 3015649
6	WCI F140602-000
7B	CLIP, HARNESS TO RH SIDE PANEL (3)
9	WCI F060976-000
11	WCI F141760-000
12	WCI F078212-200
13	TIMER POINTER
14	WCI F141025-000
16	ROTARY KNOB (2)
19	WATER TEMPERATURE SWITCH
20	WCI F078342-100
21	WCI F078922-000
22	131243800 Frigidaire Screw
23	WCI F138862-000
24	WCI F141175-000
25	134190200 Frigidaire Washer Water Valve
25B	WCI F076138-011
25A	WCI F076138-015
26	5303912532 Frigidaire Hose Inlet 60"
27	5303161296 Frigidaire Washer-Inlet Hose (1Piece)
31	SCREW SWITCH TO BRACKET ( 2 )
32	WCI F077094-000
33	218359202 Frigidaire Refrigerator Screw
33	WCI F130439-000
34	WCI F138861-000
