WFE115LXB0 02 – CONTROL PANEL PARTS
Written by
in
WFE115LXB0 02 – CONTROL PANEL PARTS
Products
Position
Product
1
W11219365 Whirlpool Panel Endcap
1
W11219370 Whirlpool Endcap Panel
1
W11219664 Whirlpool Endcap Panel
1
W11219665 Whirlpool Panel Endcap
2
Badge
3
PANEL, BACKGUARD (WHITE)
3
PANEL, BACKGUARD (BLACK)
4
WP3149404 Whirlpool Oven Surface Element Switch
4
SWITCH-INF
5
SHIELD, WIRING
6
WP9762215 Whirlpool Oven Switch
7
W10525121 Whirlpool Control Bracket
8
PANEL, MANIFOLD
9
WP8273564 Whirlpool Clip
10
3196200 Whirlpool Clip
11
W10312467 Whirlpool Knob
11
W11229681 Whirlpool Knob
12
3149360 Whirlpool Light Switch
12
WP4314961 Whirlpool Lite Switch
13
WP3196068 Whirlpool Light Lens
14
KNOB, THERMOSTAT (WHITE)
14
W10312469 Whirlpool Knob
15
Shield, Heat
16
WP8523265 Whirlpool Indicator Light
17
WP8272473 Whirlpool Rear Cover
18
3196166 Whirlpool Screw
19
SCREW
←
