WLE34200 02 – CONTROL PANEL PARTS

Products

Position	Product
1	Lamp Cover (Biscuit)
1	Lamp Cover (Black)
1	Lamp Cover (White)
2	Console-Glass (Control Panel) (Biscuit)
2	Console-Glass (Control Panel) (Black)
2	Console-Glass (Control Panel) (White)
3	Breaker, 15 Amp
4	End Cap (Biscuit Right)
4	End Cap (Black, Right)
4	End Cap (Biscuit Left)
4	End Cap (Black, Left)
4	End Cap (Right)
4	End Cap (Left)
5	Button Plug (8 mm (2))
5	Button, Plug
6	Panel, Control (Screw, (2) 8 x 3/8)
6	Spacer, Timer
6	Panel, Control
8	WP9752405FW Whirlpool Knob
8	Knobs, Control (4) (Black)
8	Knobs, Control (4) (Biscuit)
9	Light, Indicator (Surface Unit (2))
10	WP9750343 Whirlpool Light Lens
12	Trim Strip
12	Trim Strip (Black)
12	Trim Strip (Biscuit)
13	Switch, Oven Light (White)
13	Switch, Oven Light (Black)
13	Switch, Oven Light (Biscuit)
14	Outlet, Untimed (2) (Black)
14	Outlet, Untimed (2) (Biscuit)
14	Outlet, Untimed (2) (White)
15	Oven Control (Timer Assembly) Spacer, (2)
15	Insert (2) (Black)
15	Insert (2) (Biscuit)
15	Insert (2) (White)
16	Knob, Timer (17) (White)
16	Knob, Timer (17) (Black)
16	Knob, Timer (17) (Biscuit)
17	WPL 9753304
19	WP3400882 Whirlpool Screw
19	WP9750646 Whirlpool Infinite Switch
19	WP9750643 Whirlpool Infinite Switch
21	Lampholder (2)
22	Starter, Holder
23	Starter, Light
25	WPL 9755491
26	WPL 9755353PW
26	WPL 9755353PB
26	WPL 9755353PC
28	WPL 9753017
29	WP4159387 Whirlpool Compactor Screw
29	WP3400832 Whirlpool Screw
29	Base, Console
