AMK175EN2T 04 – SYSTEM AND AUTOMATIC DEFROST PARTS

AMK175EN2T 04 – SYSTEM AND AUTOMATIC DEFROST PARTS

Written by

in

AMK175EN2T 04 – SYSTEM AND AUTOMATIC DEFROST PARTS

Products

PositionProduct
*288525308000133 Frigidaire Refrigerator Clamp
*28852WCI 3006636
*28851WCI 5308009645
*28851WCI 08008781
*28851WCI 08002769
*28852WCI 5300169964
*288525304455651 Frigidaire Refrigerator Screw
*28852WCI 5300172384
1WCI G000189439
1ASPACER-COND TUBE,BLACK
2BWASHER, EXT TOOTH LOCK, NO. 10 (NON-ILLUSTRATED)
2BRACKET-MTG (4)
2A5308000039 Frigidaire Refrigerator Screw
35303305677 Frigidaire Replacement Filter Dryer Filters
4WCI 5308000021
5CORD-ELECTRIC POWER
65303001199 Frigidaire Refrigerator Wiring Harness Clamp
7WCI 5303272031
8RELAY-TL
95303006412 Frigidaire Refrigerator Cover Mounting Strap
11COMPRESSOR WITH ELECTRICALS
12CLIP – COMPRESSOR MTG
13WASHER-COMPR MTG
14218513300 Frigidaire Refrigerator Compressor Mount Grommet
15A5304455852 Frigidaire Refrigerator Screw
15CAPACITOR
175303917954 Frigidaire Refrigerator Defrost Limit Thermostat Kit
18WCI 5303281940
18AWCI 08000099
19WCI 5300187141
19A5308000110 Frigidaire Refrigerator Evaporator/Heater Primary Strap
20WCI 3007378
21WCI 5303015180
22WCI 08008749
22AWCI 5308008750
23WCI 5300170779
24WCI 3017661
26WCI 5308008753
27WCI 5308008754
28WCI 5308008755
29WCI 08008756
30WCI 08008766
31AWCI 5300171694
31WCI 5303274959
32WCI 5308008765
33WCI 5308008767
34WCI 08008769
35WCI 5308008771
36WCI 08008770
37DOOR-FRZR OUTER
38WCI 3016566
39WCI 5317053302
40WCI 5303001197
